Product Introduction

Mainly used for the decoration of interior and exterior walls and ceilings of buildings, it is a decorative material with high flatness, lightweight, and environmentally friendly without pollution. The panel is mainly made of high-quality 3-series or 5-series aluminum-magnesium-manganese alloy aluminum plate as the substrate, with a panel thickness of 0.8~1.5mm fluorocarbon coated board, and a bottom plate thickness of 0.6~1.0mm, with a total thickness of 10mm~25mm being appropriate. The core material uses hexagonal 3003 aluminum honeycomb core, with aluminum foil thickness of 0.04~0.6mm and a side length of 5~6mm. It is produced using fully automated honeycomb board composite production equipment through high-temperature and high-pressure composite processes, overcoming the brittleness of the adhesive layer in previous honeycomb boards. This ensures that the aluminum honeycomb board does not change under humid and high-temperature conditions, making it a high-quality, lightweight, high-strength, and luxurious green decorative material.

Aluminum honeycomb panels are mainly used for the interior/exterior walls and ceiling decoration of buildings. This product uses high-quality imported raw materials with precise processing dimensions. The surface adopts advanced pre-roller coating fluorocarbon paint technology, which can maintain its color for thirty years. Our company uses dual-component high polymer polyurethane adhesive film and dual-component modified polyurethane, produced through fully enclosed dust-free operations, using fully automated honeycomb board composite production equipment through high-temperature and high-pressure composite processes, making the bonding of aluminum honeycomb panels stronger, more resistant to bending, flatter, and more reliable in quality. Various special-shaped honeycomb panels such as arc panels, folded panels, and trapezoidal panels can be made according to architectural design requirements. All non-flat special-shaped panels such as circular, L-shaped, and U-shaped are formed in one go using molds, and the same project uses the same batch of roller-coated aluminum coils, ensuring no color difference. It is a high-quality, lightweight, high-strength, and luxurious green decorative material.

Product Features

Low Density: The aluminum honeycomb core structure is a porous and discontinuous material, with a very small cross-section of the solid part, resulting in low density.

Sound and Heat Insulation Performance: After the aluminum honeycomb core is compounded with the aluminum face and bottom plate, the internal space is sealed air between the aluminum plate and the honeycomb structure, preventing air flow. The transmission of heat and sound waves is greatly restricted, so aluminum honeycomb panels have good sound and heat insulation performance.

Strong Shock Absorption Performance: The aluminum honeycomb core is a component of the aluminum honeycomb panel, and the hexagonal structure restrains each other, similar to an I-beam, which can disperse and bear pressure from all sides.

Superior Flatness and Rigidity: The honeycomb core is in a vertical stress state, with countless fixed honeycombs in each panel, preventing movement and ensuring that the panel maintains high flatness under pressure and impact.
High Flatness.
Lightweight and Energy-Saving: The weight of honeycomb panels with the same rigidity is only 1/5 of aluminum plates and 1/10 of steel plates. Its cost performance is significantly higher than that of aluminum plates and aluminum single panels, effectively saving materials.
Fireproof: The National Building Materials Quality Supervision and Inspection Center has verified that the performance indicators of this material meet the requirements for flame-retardant materials.
